Wheelock NS-1215W User Manual

P84030 D
Sheet 3 of 10
Table 3: Current Ratings (AMPS) with Hi dBA Setting
Rated Average Current *
Voltage NS-2415W NS-2430W NS-2475W NS-24110W
MEAN RMS MEAN RMS MEAN RMS MEAN RMS
16.0VDC 0.102 0.102 0.140 0.140 0.230 0.235 0.340 0.358
24.0VDC 0.076 0.081 0.102 0.115 0.163 0.195 0.216 0.276
33.0VDC 0.073 0.076 0.093 0.110 0.136 0.176 0.169 0.259
16.0VRMS ------ 0.132 ------ 0.175 ------ 0.290 ------ 0.420
24.0VRMS ------ 0.118 ------ 0.156 ------ 0.254 ------ 0.340
33.0VRMS ------ 0.125 ------ 0.147 ------ 0.230 ------ 0.319
Voltage NS-1215W ------ ------ ------
MEAN RMS ------ ------ ------ ------ ------ ------
8.0VDC 0.237 0.317 ------ ------ ------ ------ ------ ------
12.0VDC 0.138 0.236 ------ ------ ------ ------ ------ ------
17.5VDC 0.101 0.168 ------ ------ ------ ------ ------ ------
8.0VRMS ------ 0.284 ------ ------ ------ ------ ------ ------
12.0VRMS ------ 0.229 ------ ------ ------ ------ ------ ------
17.5VRMS ------ 0.194 ------ ------ ------ ------ ------ ------
Rated Peak Current **
Voltage NS-2415W NS-2430W NS-2475W NS-24110W
16.0VDC 0.181 0.265 0.482 0.675
24.0VDC 0.183 0.270 0.485 0.680
33.0VDC 0.188 0.275 0.489 0.685
16.0VRMS 0.183 0.270 0.485 0.680
24.0VRMS 0.188 0.275 0.489 0.685
33.0VRMS 0.430 0.480 0.520 0.690
Voltage NS-1215W ------ ------ ------
8.0VDC 0.460 ------ ------ ------
12.0VDC 0.465 ------ ------ ------
17.5VDC 0.470 ------ ------ ------
8.0VRMS 0.465 ------ ------ ------
12.0VRMS 0.470 ------ ------ ------
17.5VRMS 0.475 ------ ------ ------
Rated Inrush Current ***
Voltage NS-2415W NS-2430W NS-2475W NS-24110W
16.0VDC 0.110 0.110 0.110 0.110
24.0VDC 0.165 0.165 0.165 0.165
33.0VDC 0.230 0.230 0.230 0.230
16.0VRMS 0.155 0.155 0.155 0.155
24.0VRMS 0.235 0.235 0.235 0.235
33.0VRMS 0.325 0.325 0.325 0.325
Voltage NS-1215W ------ ------ ------
8.0VDC 0.075 ------ ------ ------
12.0VDC 0.103 ------ ------ ------
17.5VDC 0.149 ------ ------ ------
8.0VRMS 0.100 ------ ------ ------
12.0VRMS 0.139 ------ ------ ------
17.5VRMS 0.189 ------ ------ ------
* Rated average current is measured using mean value.
** The time duration for the peak current is 100 microseconds.
*** The time duration for the inrush current is 4 milliseconds.

Wheelock NS-1215W Specifications

General

Brand	Wheelock
Model	NS-1215W
Category	Security System
Language	English
