WHIRLPOOL CORPORATION assumes no responsibility for any repairs made
on our products by anyone other than Authorized Service Technicians.
FORWARD
This Whirlpool Job Aid, “2003 - 5000 & 6000 BTU Air Conditioners” (Part No. 8178279), provides
the technician with information on the installation and service of the 2003 - 5000 & 6000 BTU Air
Conditioners. It is to be used as a training Job Aid and Service Manual. For specific information
on the model being serviced, refer to the “Use and Care Guide” provided with the air conditioner.
The Wiring Diagrams and Strip Circuits used in this Job Aid are typical and should be used for
training purposes only. Always use the Wiring Diagram supplied with the product when servicing
the unit.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide detailed information that will enable the service technician to
properly diagnose malfunctions and repair the 2003 - 5000 & 6000 BTU Air Conditioners.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• Successfully troubleshoot and diagnose malfunctions.
• Successfully perform necessary repairs.
• Successfully return the air conditioner to its proper operational status.
Copyright © 2003, Whirlpool Corporation, Benton Harbor, MI 49022
