SERVICE
Whirlpool Europe MT 263/WH 27.01.1998 / Page 7
Customer Service 8538 263 53291 Doc. No: 4812 714 12124
Quick Heat (El Convection and Fuzzy Crisp Convection only)
The Quick heat function is used to warm up the empty oven to a wanted temperature as fast as possible. (Both
the grill and the forced air are switched on simultaneously).
Press the Quick heat button repeatedly until the desired temperature (in C) is displayed.
Press the Start button (no cooking time shall be selected). The oven starts and the set temperature is
displayed. When the set temperature is reached, the oven beeps three times and automatically switches over
to Forced air (see display symbols).
(If you don’t open the door the temperature will be kept for ten minutes, the oven beeps every minute and
then it switches off). Place the food in the oven, select time and press the START button.
Turn Table Stop
The Turn Table Stop switch is used to select between rotating and non rotating turntable. Some functions
require that the turntable is rotating however.
Stop
The STOP button aborts any operation started, and returns the oven to standby.
If the door is left open one extra press of the Stop button will switch of the light.
Microwave Power Control
Power table and timings
The peak microwave power is specified in the technical specification of the oven. To obtain lower power levels,
the magnetron is switched on and off. The cycle time is 20 seconds. The magnetron is on during a portion of
the cycle time, then it is switched off until the beginning of the next cycle. The on-time varies depending on
which power level has been selected.
Power table 50 Hz
Indicated
power (W)
Cycle
Time (s)
On time from
contr. system (s)
Start delay
time (s)
Effecive
on time (s)
90 20.5 3.5 1.5 2
160 20.5 5 1.5 3.5
350 20.5 9 1.4 7.6
500 20.5 12.1 1.3 10.8
650 20.5 15.3 1.2 14.1
750 20.5 17.2 1 16.2
850 20.5 18.9 0.5 18.4
