Whirlwind Q4 User Manual

1. After you have fully charged your Electric Quad Bike, it is ready to be driven.
2. Insert the Key into the power socket on the Quad Bike (this is found on the right side of
the vehicle) and turn to ‘Power On’.
3. The Drive Mode switch in the center of the Quad Bike has three modes: Forward, Neutral
and Reverse. Put it into Forward mode if you want to go forwards.
4. Then twist the Throttle to slowly accelerate forwards.
5. The display next to the throttle indicates how much battery life is remaining in the Q4.
Where Green light is sufcient battery life and Red being low and that the vehicle needs
to charge.
6. Lastly, there is a horn that can be used by pressing the Red button on the left handlebar.
Operating Instructions
5.
WHIRLWIND Q4 USER MANUAL10
Technical Parameters
6.
Drive mode Throttle Assisted. Chain Mechanic
Weight (kg) 34
Max Speed (mph) 15.5
Max Range >8 miles
Max Climbing Angle 20°
Battery Capacity 36V 8.8AH
Battery Type Lithium
Battery Brand Samsung
Charge time (hours) 4-6
Max Loading 50KG
Wheel Size (Inches) 4
Size (mm) (H) 1000 x (W) 590 x (D) 600
WHIRLWIND Q4 USER MANUAL 11

Whirlwind Q4 Specifications

General

Brand	Whirlwind
Model	Q4
Category	Offroad Vehicle
Language	English
