W6 84
Pin MASS Connector System
Technical Data - Crimp Type
Input
2.75“
Strip wire 0.156“
1.75“
Insulator covers
transition between
foil and wires
The W6RP is a rear insert, rear release crimp type connector. Contacts are
loaded into the insert body and removed from the rear (wiring side) of the
housing. To prepare the wires for use follow the diagram for removing the
jacket and the foil shield from the cable pair. Be careful not to nick and do not
tin the ends of the wire being stripped. Insulate the drain wires with the clear
PVC tubing and use the heat shrink tubing over the foil of each pair.
The whirlwind M1R-Tool Kit contains the required tools to attach the
contacts to the wires and to load or remove them from the insert housing. The
crimp tool body is a mil spec Daniels AFM8 with a K13-3 contact locator. The
contact insertion/extraction tool is an AMP 91067-2.
Before attaching contacts to the wires, the selector knob on the top of the
crimp tool must be set for the proper gauge. Setting 5 is for 24 AWG such as
whirlwind multipair cable and setting 6 is for 22 AWG such as Belden 8451 and
1266A.
DATAPLATE
SELECTOR
KNOB
AFM8
Crimp Tool
K13-3
LOCATOR
WIRING SIDE OF CONNECTOR
PINS
SOCKETS
27
27 27 21
G G
25 25 25 23 23 23 21 21
G G
15 15 1517 17 1719 19 19
GGG
5 57 5
GG
33 3
G
11 17
34 35 37 3836 39 40 413332 42
24 25 27 2826 29 30 312322
14 15 17 1816 19 20 2113
6 7 9 108 11 125
1 2 3 4
13 137 13
GG
11 1111
G
99 9
G
GGG
668 6 4 44 22 28
GGG
10 108 1212 121414 14 10
G
16 16 1618 18 1820 20 20
GGG
28
28 28 22
G G
1 2 3 4
6 7 9 108 11 12
14 15 17 1816 19 20 2113
5
24 25 27 2826 29 30 312322
34 35 37 3836 39 40 413332 42
222224 24 2426 26
G G
26
PIN
SOCKET
1
3
5
7
9
11
13
15
17
19
21
23
25
27
BLACK
BLACK
BLACK
BLACK
RED
RED
RED
GREEN
GREEN
WHITE
WHITE
BLUE
BLUE
BROWN
RED
GREEN
YELLOW
ORANGE
GREEN
YELLOW
ORANGE
BLUE
BROWN
BLUE
BROWN
YELLOW
ORANGE
ORANGE
28 Pair Color Code
ORANGE
BROWN
BLUE
WHITE
WHITE
GREEN
GREEN
GREEN
RED
RED
RED
BLACK
BLACK
BLACK
YELLOW
YELLOW
BROWN
ORANGE
YELLOW
ORANGE
YELLOW
WHITE
BROWN
BLUE
WHITE
BROWN
BLUE
WHITE
28
26
24
22
20
18
16
14
12
10
8
6
4
2
INPUT
XLR
Pin 3 Pin 2 Pin 1
G
Pair #
XLR
Pin 3 Pin 2 Pin 1
G
Pair #
