134T696H190 38" Lawn Tractor Hydrostatic LT-165 (1994) Page 2 of 24
Drive Assembly
Ref # Part Number Qty DescriptionS/P/F
1 717-0983 Electric Clutch1 S
2 710-3008 Hex Bolt 5/16-18 x 3/4" Lg. (Gr. 5)1 /P
3 736-0242 Bell-Wash. .345" I.D. x .88" O.D.1 /P
4 731-1053B Index Bracket1 S
5 710-0924 Pan Hd. Mach. Scr. 1/4-20 x .75" Lg.1 /P
6 710-0599 Hex Wash. Hd. TT-Tap Scr. 1/4-20 x .5" Lg.1 /P
7 712-0138 Hex Nut 1/4-28 Thd.1 S
8 736-0329 L-Wash. 1/4" I.D.1 S/F
?9 750-0777 Shld. Spacer .38" I.D.1
10 710-0412 Hex Bolt 1/4-28 x .75" Lg.1 /P
11 683-0065 Lower Frame Ass'y.1 S
12 710-1035 Hex Tap Scr. 3/8-16 Thd.1 /P
13 736-0247 Fl-Wash. .406" I.D. x 1.25"1 /P
14 725-1426 Solenoid1 S
15 736-0222 Ext. L-Wash. 1/4" I.D.1 S
16 17358D Belt Guard Brkt. Ass'y. Code: N notates a
new part (not previously existing).
1 S
17 714-0128 Sq. Key 1/4" x 1" Lg.1 /P
18 756-0576 Engine Pulley1
19 17418 Torque Brkt.1 S
20 738-0785 Shld. Spacer .445" I.D.1 S
21 736-0171 L-Wash. 7/16" I.D.1 S/F
22 710-1067 Hex Bolt 7/16-2O x .5" Lg.1 /P
23 735-0196 Foot Pad1 S
24 683-0049 Brake Lockout Brkt. Ass'y.1 S
25 783-0091A Foot Pedal Brkt. Code: N notates a new part
(not previously existing).
1
26 732-0728 Foot Pedal Return Spring1
27 738-0296 Shld. Bolt .437" Dia. x .268"1 S
28 736-0406 Fl-Wash. 7/16" I.D. x 1-3/8" O.D.1 S
29 747-0608 Lock-up Rod Code: N notates a new part (not
previously existing).
1 S
30 17755A Bracket1
31 736-0119 L-Wash. 5/16" I.D.1 S/F
32 712-0267 Hex Nut 5/16-18 Thd.1 S/F
33 720-0166 Ball Knob1 /P
34 732-0727 Neutral Return Spring1 S
35 712-0273 Hex Nut 5/16-24 Thd.1 S
36 736-3078 Fl-Wash. .344" I.D. x 1" O.D.1 /P
37 783-0092 Scissor-Flat1
38 736-0362 Fl-Wash. .33" I.D. x 1.25" O.D.1 /P
39 750-0808 Spacer1 /P
40 736-0219 Bell-Wash. .4" I.D. x 1.13" O.D.1 S
41 761-0196 Friction Washer1 S
42 750-0918 Centering Gauge Spacer1
43 783-0095 Neutral Return Mtg. Brkt.1
44 736-0270 Bell-Wash. .265" I.D. x .75" O.D.1 /P
45 732-0718 Comp. Spring 1.19" Lg.1
46 736-3008 Fl-Wash. .312" I.D. x .75" O.D.1 S
47 712-0123 Hex Nut 5/16-24 Thd.1 /P
48 710-0299 Hex Bolt 1/4-28 x 1" Lg. (Gr. 5)1
