Fig. 1-1
15
16
17
2
Pleaserecordidentificationnumbers
below. You should provide these
numbers when ordering parts and
accessoriestoinsureaccuracy.
DateofPurchase
_______________________
ModelNo:
_______________________
SerialNo.:
_______________________
Allinformation,illustrationsandspecificationsin
thismanualarebasedonthelatestinformationat
thetimeofpublication.Therightisreservedto
makechangesatanytimewithoutnotice.
COPYRIGHT©2001‐2008
1
1–Handle–Toploop
2–Handle–Sideupright(2)
3–Hpiece
4–Snaplockknobs(2)
5–Handleconeassembly
6–ExtensionCordhook–plastic(3)
7–IdentificationPlate
8–MotorProtectorBreaker
9
–RemovableFlap
10–Largeextensioncordhook
11–4ftpowercord–frombase
12–4intransportwheels(2)
13–StorageTray
14–ExtensionCordStrainReliever
15–GearSideHousing
16–ElectricalSideHousing
17–MachineBase
