10
Error Codes of Error LED (FLT)
Blink code Cause of error
static Secondary error on modules that have not discovered the error themselves
2x Error in module configurations on S1, S2, S3, other module configuration
3x Rotary switch altered during operation
4x Module location list comparison when power switched on has detected a difference (including alteration of rotary switch position
before or during power off)
5x Voltage supply internal and external
6x Self-monitoring, internal error, etc. (e.g. enter button pressed longer than 3 s)
Technical Data
Power circuitry (A1, A2) Min. Typ. Max.
Operating voltage U
B
, DC DC 19.2 V DC 24 V DC 30 V
Rated voltage U
N
-- DC 24 V --
Residual ripple Uss -- -- 3.0 V
Rated power DC -- -- 1.8 W
Peak current I
P
-- -- 25 A
Ready time t
on
(after connecting U
B
) -- -- 10 s
Class gG fuse or circuit-breaker 6 A with tripping characteristic B or C
Input circuit (I1 – I4, EN, S1 – S3) Min. Typ. Max.
U
e
(HIGH 13.0 V -- 30 V Input voltage
U
e
(LOW) -5.0 V -- 5.0 V
I
e
(HIGH) 2.4 mA 3.0 mA 3,8 mA Input current
I
e
(LOW) -2.5 mA -- 2,1 mA
ON period t
E
70 ms -- --
OFF period t
A
> operate time t
AN
Break time of U
E
(test pulse) -- -- 1.0 ms
Synchronous time t
S
(Function 1, 2) -- -- 1500 ms
Synchronous time t
S
(Function 4, 5.2) -- -- 500 ms
Synchronous change time t
SW
(only with FUNCTION 4) 94 ms -- 100 ms
Output circuit (X1, X2) Min. Typ. Max.
Output voltage 18.0 V -- 30.0 V
Output current -- -- 150 mA
Function 3.1, 7, 8 -- no test pulses --
Function 3.2 (BWS type 2) -- 12 ms --
Function 3.2 (PDF sensors) -- 52 ms --
Test pulse width t
TI
Function 1, 2, 4, 5, 6, 9 -- 12 ms --
Function 3.1, 7, 8 -- no test pulses --
Function 3.2 (BWS type 2) -- 20 ms --
Function 3.2 (PDF sensors) -- 70 ms --
Test duration t
TD
Function 1, 2, 4, 5, 6, 9 -- 20 ms --
Function 3.1, 7, 8 -- no test pulses --
Function 3.2 (BWS type 2) -- 40 ms --
Function 3.2 (PDF sensors) -- 384 ms --
Test pulse period T
TP
Function 1, 2, 4, 5, 6, 9 -- 40 ms --
Load capacitance C
L
-- -- 500 nF
Line length (simple, 1,5mm
2
) -- -- 100 m
Short-circuit behaviour absolutely short-circuit-proof
Output circuit (Q1, Q2, Q3, Q4) Min. Typ. Max.
Output voltage 18.0 V -- 30 V
Output current (at U
N
) -- -- 2.0 A
Total current (see diagram ‘Total current vs. temperature’) -- -- 4.0 A
Test pulse width t
TI, HL
-- 500 s --
Test pulse period T
PI, HL
32 ms -- 80 ms
Load capacitance C
L
-- -- 500 nF
Inductive switching off energy E (E = 0.5 * L * I
2
) -- -- 370 mJ
Line length (simple, 1,5mm
2
) -- -- 100 m
*Operate time t
AN
Function 3.1, 7, 8, 9 -- -- 13 ms
Function 1 (except safety mat), 2, 4, 5.1, 6,9
-- -- 20 ms
Function 1 (safety mat) -- -- 38 ms
Function 5.2 -- -- 29 ms
Function 3.2 (BWS type 2) -- -- 32 ms
Function 3.2 (PDF sensors) -- -- 79 ms
OR off to Qx off -- -- 9 ms
Function 3 (MUTING off to Qx off) -- -- 65 ms
EN off to Qx off -- -- 13 ms
0 / 0,5 / 1 /1,5 / 2 / 2,5 / 3 / 3,5 / 4 / 5 s
0 / 5 / 10 / 15 / 20 / 25 / 30 / 35 / 40 / 50 s
Settable release delay t
RV
Q3/4 or Q4
(depending on device version)
0 / 0.5 / 1 / 1.5 / 2 / 2.5 / 3 / 3.5 / 4 / 5 min
Short-circuit behaviour absolutely short-circuit-proof
