WiFi CONNEkT Starter Kit - Page 14

14
HOW TO CONNECT
MASTER SOCKET ADD-ON SOCKET ADD-ON SOCKET
Powerline
ROUTER CONNECTION
Router can be connected to the
Master Socket via a network cable or
a WiFi connection
HARDWIRE CONNECTION
Add-On Socket connected to a
device via a network cable
WIFI CONNECTION
Add-On Socket connected to a
device via a WiFi connection
