Rail
U-shape stator
U-shape stator
1
2
3
4
c. Adjust the tent to the roofs centre,
ensuring the rear door can be opened
/closed
d. Slide the M8X50 hexagon bolt into
the rails from both sides ensuring you
have positioned 8 in total(see picture
1),replace the plastic covers of your
roof racks(see picture 2)
e.Use the plastic nut, flat and arc washer to fix the M8X50 hexagon head bolt and
U-shape stator in place to all four corners.(see picture 3)
