CONNECTING UP YOUR TORUS AMPLIFIER
Method 2:
USING LOW LEVEL TORUS AMPLIFIER INPUT
Figure 2. Shows a diagram of how to connect the low level input of the Torus Amplifier. Using a
pair of RCA to RCA interconnect (not supplied), plug them into the Torus Amplifier low level
input and the other ends into the dedicated sub output on your amplifier or processor. If a
dedicated sub output is not available then you can use a spare set of pre-amp outputs.
If you only have a single sub woofer output socket on your equipment then connect it with just
one of single interconnect. In this instance use the Left input on your Torus Amplifier.
Please Note that high and low level connections can be used at the same time if required.
This gives you the advantage of being able to connect up a Hi-Fi and AV system
simultaneously.
Method 2 - To Connect to a Preamplifier / Pre-Out or Processor
Using the low level input & RCA Interconnects
figure 2.
RIGHT
LEFT
LFE / SUB OUT
Stereo Output To Other
