Wilton 4103 Operating Instructions

15
Parts List - Square Wheel Belt Grinder
Ref. Part
No. Number Description Qty.
Ref. Part
No. Number Description Qty.
1 5510944 Contact Wheel Assy, 10 x 2 Serrat, 90 Duro 1
5510943 Contact Wheel Assy, 8 x 2 Smooth, 50 Duro 1
5510942 Contact Wheel Assy, 8 x 2 Serrated, 50 Duro 1
2 5044590 Contact Wheel Assy, 1-1/2 x 2 1
3 5044610 Contact Wheel Assy, 3 x 2 1
3A 9049821 Screw, Flat Head Cap 2
4 5507582 Idler Wheel 1
5 9100331 Bearing 2
6 9074011 Retaining Ring, Internal 2
7 9074081 Retaining Ring, External 2
8 5510946 Contact Wheel, 8 x 2 Serrated, 50 Duro 1
5510947 Contact Wheel, 8 x 2 Smooth, 50 Duro 1
5510948 Contact Wheel, 10 x 2 Serrated, 90 Duro 1
9 5053231 Shaft, 8 x 10 Wheel 1
10 9074381 Retaining Ring, External 1
11 9112811 Abrasive Belt, 2 x 72, 50 Grit (Standard -
optional grit below) (10 piece minimum order) 1
12 5044400 Platen Casting 1
13 5044410 Work Rest Casting 1
14 5044370 Head Casting 1
15 9128441 Screw, Socket Head Cap 3/8-16 x 1 1
16 5049990 Screw, Work Rest Machine 1
17 9129881 Screw, Socket Head Cap 3/8-16 x 5/8 2
18 9055361 Flat Washer, Nylon 1/2 I.D. x 1 O.D. 1
19 9129861 Scr, Socket Head Cap, Fll Thrd, 3/8-24 x 3 1
20 5046571 Bearing, Idler Housing 1
21 9055381 Flat Washer, Nylon, 3/8 2
22 9010271 O-Ring, 1/2 1
23 5044651 Cap, Idler Housing Pin 1
24 9133041 Set Screw, Socket Head 1/4-20 x 1/4 1
25 5046560 Lever, Tension 1
26 9133191 Set Screw, Nylon Tipped 5/16-18 x 3/4 1
27 9129561 Locknut, Hex, 3/8-24 1
28 9059811 Roll Pin, 3/16 x 1-1/2 1
29 5053301 Shaft, Idler Pulley 1
30 5541241 Switch (Model 4103 only) 1
5644231 Manual Motor Starter (Model 4106 only) 1
31 9066821 Motor & Switch, 1 HP, 1
Single Phase (Model 4103) 1
9066831 Motor, 2 HP, 3 Phase (Model 4106) 1
5508076 Motor, 1 HP, 3-Phase (Model 4126AC only) 1
32 9070361 Knob, Hand 1
33 9070781 Nut, Allen, 5/16-18 1
34 9128671 Bolt, Hex Head, w/Nylock 3/8-16 x 3/4 4
35 9114320 Key, 3/16 x 3/16 x 1-1/4 1
36 5044511 Pulley, Drive 1
37 9054541 Set Screw, Socket Head 5/16-18 x 1/2 2
38 5630451 Screw, Socket Head Hex 5/16-18 x 1-1/2 1
39 5077041 Lock Washer, 5/16 2
40 9070381 Latch, Cam 1
41 5630061 Nut, Hex, 5/16-18 1
42 5507583 Washer, Nylon 5/16 2
43 5055311 Door 1
44 9070371 Knob, Hand 1
45 5044630 Guard Flap Assembly 1
46 9057461 Washer, Flat 0.26 x 0.63 x 0.06 1
47 5046600 Tracking Leader Assembly 1
48 5046540 Casting, Idler Housing 1
49 5541030 Main Frame Assembly 1
