Page 6 For technical questions, please call 1-800-444-3353. Item 93454
9. Use the Hex Wrench and Screws (6) to fasten the tops of the
Legs to the Table Top underside. See Figure I, right.
10. Use the Hex Wrench and Screws (13) to fasten the sides of
the Legs to the Table Top underside. See Figure J, right.
Note: There are no pilot holes available for this step, so you
will need to use a drill to make the pilot holes before threading
in Screws.
11. Set the Lower Support (15) across the top of the Sliding
Partition and against the sides of the Legs. Then use
Screws (6) to fasten each end of the Lower Support to the
sides of the Legs. See Figure K, right.
Leg (4)
Hex
Wrench
(9)
Figure I
Table
Top (1)
Figure J
Table
Top (1)
Leg (4)
Figure K
Lower
Support
(15)
Screws (6)
Leg (4)
