Windsor Saber Glide SG28 Operator Instructions

DUAL VACUUM MOTOR-OPTION
86037580 GLIDE 01/03/07
5-76
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86233140 20041 4 CLAMP, 2.0” WORM GEAR
2 86076840 40092 1 HOSEBARB, 1.50 TEE MACHINED
3 86004370 39547 1 HOSE ASM, 1.5 BLK VAC X 21
4 86007770 73566 3 SPACER, 1/2 OD X 3.0 W/1/4-20 AL
5 86276370 70638 3 SCR, 1/4-20 X 1.75 SSSCU
6 86005450 53799 1 VAC MOTOR ASM, 36VDC 3 STAGE
- 86230800 140550 1 BRUSH SET, VACUUM AMETEK SERVICE ONLY
- 86135310 140686 1
BRUSH SET, VAC 24V/36V
WINDSOR
SERVICE ONLY
7 86005620 57021 3 NUT, 1/4-20 X .962 WELL
8 86235780 34164 1 FERRITE CLAMP, 1.14 X 1.28 X .583
9 86003750 35122 1
GASKET, 230V C17EI/C20 VAC
MOTOR
10 86010780 87162 3 WASHER, 1/4 SPLIT LOCK
11 86273830 70020 3 SCR, 1/4-20 X 1.2 HHCS SS
12 86076800 39612 1 HOSE, 1.5 ID X 2.0 L

Windsor Saber Glide SG28 Specifications

General

Brand	Windsor
Model	Saber Glide SG28
Category	Scrubber
Language	English
