SQUEEGEE-32 IN
86037580 GLIDE 04/11/11
5-42
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86351700 1 PLATE, SQUEEGEE BOTTOM
2 86351680 1 PLATE ASM, SQUEEGEE TOP 37"
3 86351630 1 BAND, FRONT SQUEEGEE
4 86351560 1 PLATE, SQU. VERT. FILL. 32" R
5 86351550 1 PLATE, SQG. VERT. FILL. 32" F
6 86277000 2 SCR, 1/4-20 X 1.75 CARRIAGE SS
7 86276990 2 SCR, 3/8-16 X 3.50 CARRIAGE SS
8 86276980 2 SCR, 5/16-18 X 2.00 HHCS SS
9 86276870 2 SCR, 3/8-16 X 2.50 CARRIAGE SS
10 86274130 2 SCR, 8-32 X 3/8 PHTC 'F' PLTD
11 86271820 3 NUT, 5/16-18 CAPTIVE "J" PLTD
12 86270830 2 NUT, 5/16-18 HEX NYLOCK SS
13 86069870 2 BRKT, SQG WHEEL
14 86011020 4 WHEEL, 3" DIA. CUSHION RUBBER
15 86010680 4 WASHER, 3/8 X 3/4 NYL
16 86010670 4 WASHER, 5/16 X 3/4 SS
17 86009910 1 VIAL, LEVEL
18 86009890 1 WELDMENT, REAR SQG BAND SHORT
19A 86009840 1 SQUEEGEE, REAR BLADE LINATEX
19B 86009960 REF SQUEEGEE REAR BLADE BLUE TILE OPTION
19C 86009980 REF SQUEEGEE, REAR BLADE BUTTONS OPTION
19D 86255700 REF SQUEEGEE BLADE REAR URETHANE 37” OPTION
20 86009830 1 SQUEEGEE, FRONT BLADE LINATEX
21 86009820 1 WELDMENT, REAR SQUEEGEE BAND
22 86009200 2 KNOB, 3/8-16 4 PRONG
23 86009180 1 STRIKER, SQUEEGEE STRAP REAR
24 86009170 1 LATCH, SQUEEGEE STRAP
25 86008660 2 COTTER, 5/16 RING
26 86008390 1 TUBE, SQUEEGEE VAC
27 86007780 2 SPRING, COMP .60D X2.0 X.045
28 86007040 3 SCR, 5/16-18X1 THUMB SS TYPE P
29 86006400 4 RIVET, 5/32 OD X 1/8 GRIP
30 86006270 2 PIN, CLEVIS
31 86005810 2 NUT, 1/4-20 HEX NYLOCK SS
32 86005650 2 NUT, 5/16-18 HEX
33 86005630 4 NUT, 3/8-16 HEX NYLOCK THIN SS
34 86004890 2 KNOB,4 PRONG ALUM 3/8-16 NUT
35 86001350 4 BUSHING, SPANNER .435 X 1.10
NOTE: COMPLETE SQUEEGEE ASSEMBLY IS AVAILABLE, PN 86008450.
