SOLUTION TANK
86221970 17” SCRUBBER 08/07/09
5-20
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86239620 41385 1 HINGE, 17 IN SCRUBBER
2 86010660 87025 6 WASHER, 1/4 LOCK EXT STAR SS
3 86276700 70716 4 SCR, 1/4-20 X 1/2 PTHMS
4 86003210 27906 1 CABLE, TANK LANYARD
5 86278260 70298 2 SHOULDER BOLT, 5/16 X 3/8 SSHLD
6 86215820 140886 1 BRKT, TANK SUPPORT
7 86234790 27827 1 COVER, SOLUTION TANK
8 86279880 27425 1 CORD, 1/8” X 16”
9 86282110 39571 1 HOSE, 1/2” ID WIRE BOUND X 5.5”
10 86197940 40027 2 HOSEBARB, 3/8 MPT X 1/2 90 D
11 86069410 140406 1 BRKT, VALVE MOUNT
12 86224430 730375 1 SPACER, .259 ID X 3/8 OD X .37
13 86221750 51418 1 LEVER, SOLUTION CABLE
14 86222280 57307 1 NUT, 10-32 HEX NYLOCK SS
15 86328920 - 1 SCR, HHSS, M4X5.3 SS WAS 70403
16 86006980 70591 3 SCR, 10-32 X 1/2 HHCS SS
17 86010650 87018 1 WASHER, #10 X 9/16 OD
18A 86282090 39569 1 HOSE, 3/8” ID X .05 W CLR X 12” NYLOBRD
ALL
EXCEPT
SCHC172
18B 86281640 39471 1 HOSE, 1/2” VINYL X 15” NYLOBRD SCHC172
19A 86240430 40083 1 HOSEBARB, 3/8 MPT X 3/8 NYLON
ALL
EXCEPT
SCHC172
19B 86001590 40049 1 HOSEBARB, 3/8 MPT X 1/2 NYLON SCHC172
20 86248020 81380 1 NUT, SEALED BULKHEAD
21 86225680 84201 1 VALVE, 3/8 FPT BALL
22 86233110 20018 1 CLAMP, 1.0 WORM GEAR
23 86219160 40108 1 HOSEBARB, 1/2 MPT X 3/4 90D
24 86282100 39570 1 HOSE, 3/4 ID X .12 W CL X 36 L
25 86005640 57030 2 NUT, 10-32 HEX NYLOCK
26 86276820 70740 6 SCR, 10-32 X 1/2 PPHMS BLK
27 86242100 48083 1 KNOB, SOLUTION LEVER
28 86240810 830156 1 HOSEBARB, 1/2 MPT X 3/4
29 86007350 730040 1 STRAINER, 3/8” NPT 20 MESH
30 86198450 20005 1 CLAMP, 5/16 NYLON
31 86221020 501102 1 LABEL, VENT/DRAIN
32A 86322090 - 1 TANK, SOLN SC17 DK BLU
**
ALL
EXCEPT
HCC172
WAS
86032460
32B
86327580
- 1 TANK, SOLN SC17 DK GRY
**
HCC172
WAS
86032470
33 86274290 70162 1 SCR, 10-32 X 3/8 PPHMS SS
34 86279190 87095 1 WASHER, #10 FLAT PLTD
35 86279790 87489 1 WASHER, #10 X 9/16 OD
** CALL MANUFACTURER FOR SERIAL NUMBER
