ONBOARD CHARGER
86221970 17” SCRUBBER 10/12/09
5-30
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL
NO.
NOTES:
1 86216670 270051 1
CHARGER, CURTIS 1608, 17
INCH
2 86215790 140880 1 BRKT, 17 IN CHARGER
3 86215780 140879 1 BRKT, TOP 17 IN CHARGER
4 86218060 35357 2 GASKET, 4.25 L X .55 W X .38
5 86220720 501033 1 LABEL, CHARGER 1608FS SERVICE ONLY
6A 86234390 23725 1 CORD ASM, 16/3 SJTW X 2M IEC
THAILAND,
TAIWAN, US
SERVICE PART
6B 86217090 23726 1 CORD ASM, 16/3 AUST X IEC
AUSTRALIA, CHINA
SERVICE PART
6C 86217100 23727 1 CORD ASM, 16/3 UK X IEC
MALAYSIA, HONG
KONG,
SINGAPORE, UK
SERVICE PART
6D 86217110 23728 1 CORD ASM, 16/3 EURO X IEC
INDONESIA,
KOREA, EURO
SERVICE PART
7 86274290 70162 4 SCR, 10-32 X 3/8 PPHMS SS
8 86279190 87095 4 WASHER, #10 FLAT PLTD
9 86198450 20005 1 CLAMP, 5/16 NYLON
10 98408080 - 1 KIT, 17” SPE CHARGER **
11 86323400 - 1 BRKT, 17” CHARGER SPE RIGHT **
12 86323410 - 1 BRKT, 17” CHARGER SPE LEFT **
**CALL MANUFACTURER FOR SERIAL NUMBER
