SKIP & MOUNTING FRAME 1 - A - 1
Item Part no Description Qty
1 V2005429 SKIP 1
2 V2005410 FRAME, skip mounting 1
3 V2005397
RAM, skip tipping (see page 2-R-1 )
2
4 V2005341 PIN, ram rod 1
5 V2005342 PIN, ram body 1
6 267S09 WASHER, flat 4
7 44S16J PIN, split 4
10 V2005423 PIN, skip pivot 1
11 V2005403 PIN, lynch 2
15 11S05K SCREW, set 2
16 7S05 NUT 4
17 17S06 WASHER, spring 2
20 187S08EE CLAMP, hose 1
21 68S04F SCREW, cap head 1
22 267S05 WASHER, flat 1
24 61S03 NUT, "Binx", self locking 1
25 SB1321 SUPPORT, skip 1
26 V601147 PIN, feather 'R' clip 2
October 2003
Serial no
