SCISSOR & CHASSIS 1 - A - 2
1 V2005436 SCISSOR, welded assembly 1
2 V2005415 ROLLER 4
3 V2005417 SPACER, upper 2
4 V2005416 SPACER, lower 2
5 V2005424 PIN, scissor upper pivot 1
6 V2005424 PIN, scissor lower pivot 1
7 V2005403 PIN, lynch 4
8 131S02 NIPPLE, grease 1
9 176S01 CAP, grease nipple 1
15 V2005330 RAM, scissor lift (see page 2-R-1 ) 2
16 V2005408 PIN, ram eye 1
17 V2005401 PIN, ram cylinder 1
18 44S03F PIN, split 2
19 44S16J PIN, split 2
19A 267S07 WASHER, flat 2
20 V2005392 CHASSIS, subframe 1
21 11S04D SCREW, set 8
22 267S06 WASHER, flat 16
23 17S05 WASHER, spring 8
24 7S04 6
25 59S03 NUT, "Nyloc", self locking 2
October 2004
NUT
