TANK, hydraulic 2 - C - 1
Item Part no Serial no Description Qty
1 SB1015
VALVE, control,
1
2 8S03F BOLT, 50mm long 1
2A 8S03H BOLT, 60mm long 1
3 267S05 WASHER, flat 4
4 17S04 WASHER, spring 2
5 7S03 NUT 2
10 V2005359 FILLER/BREATHER 1
11 68S02A SCREW, slotted head 3
15 V2005347 TANK, hydraulic 1
15A 153S01 CLAMP "U" Bolt (not illustrated) 1
16 11S03C SCREW, set 2
17 17S04 WASHER, spring 2
18 267S05 WASHER, flat 2
20 411411135 STUD 1
21 267S06 WASHER, flat 1
22 17S05 WASHER, spring 1
23 324S04 NUT 1
25 V2005355 FILTER, suction 1
26 V2005356 GASKET, filter mounting plate 1
27 V2005360 PLATE, filter mounting 1
28 267S04 WASHER, flat 4
29 17S03 WASHER, spring 4
30 7S02 NUT 4
31 186S02 WASHER, nylon 4
35 V2005269 INDICATOR, oil level 1
36 127S04 PLUG, drain 1
37 100S04 SEAL, bonded 1
40 902S02 PIN, lynch c/w chain 1
41 V2004217 PIN, scissor safety lock 1
AUGUST 2007
