10-11
SECTION 10 –
SLIDEOUT ROOMS AND LEVELING
NOTE: When parking at an uneven site, always
park the front of the vehicle to the
downhill side. This allows you to level by
raising the front end rather than the rear.
Since only the rear wheels are locked
while in PARK, raising either one or both
of the rear wheels off the ground could
allow the vehicle to roll off the jacks.
Auto Level Remote Switch
In addition to the Leveling System Control
Panel, there is an additional remote switch for
your leveling convenience.
This switch allows you to extend or retract
your jacks and observe them at the same time. It
also allows you to stop them suddenly, if needed,
without having to climb in and out of the coach.
The Auto Level Remove switch is located in
the utility compartment.
Jacks Down Light
The “Jacks Down” reminder is intended to
warn you to retract your Leveling Jacks before
moving the vehicle. The light will come on
briefly and a chime will sound when the ignition
key is turned to the On or Run positions if the
jacks are down.
• Keep all people clear of the coach
while the leveling system is operating.
• When extending the rear stabilizers,
do not lift the wheels beyond ground
contact. This makes it possible for the
vehicle to roll unexpectedly forward (or
backward) off the jacks. This could
cause severe injury or death.
• Do not use the levelers on icy or slick
surfaces on which the foot pads may
slip.
• Do not use leveling jacks to support
the vehicle for service or tire changing.
• Do not use the leveler as an
emergency brake. They are not
designed for any type of vehicle
braking purpose.
• Never check for hydraulic fluid leaks
using your hands and/or any other
body part. The leaking fluid is under
pressure and is capable of cutting and
penetrating your skin, resulting in
severe injury.
Auto Level Remote Switch
(Located in the utility compartment)
-Typical View
“Jacks Down” Light
(Located on dash)
-Typical View
