Pre-wash zones (optional)
The pre-wash zones are used for scraping the wash items.
Pre-wash zone S Pre-wash zone M
1 2 3
45
1 2 3 4 5
6789
Item Name Item Name
1 Rack bracket 1 Door
2 Long curtain (length: 520 mm) 2 Long curtain (length: 520 mm)
3 Rack conveyor with push bars 3 Rack bracket
4 Filter cassette 4 Rack conveyor with push bars
5 Wash arms (top: 1; bottom: 1) 5 Short curtain (length: 445 mm)
6 Tank
7 Strainer
8 Wash arms (top: 2; bottom: 2)
9 Filter cassette
