Wolf Garten Loopo S150 - Powering Up the System

28 29
Power
up
1. Connect the wire tail marked A to the A terminal and the other tail
to the B terminal of the Base Station head.
2. Connect the power supply connector to the Base Station head as well.
3. Note the markings for placing the Base Station Head.
Markings for placing the Base Station Head
