Integrated Modules
Integrated Modules
Component Removal
3-22
#826498 - Revision B - December, 2016
Figure 3-43. SM15 User Interface
User Interface
To remove the user interface, first remove the pan
assembly steamer, fryer, then (See Figure 3-43):
Use a putty knife or small screw driver to peel the1.
user interface from the glass.
User Interface
Connection
To Next Page
