Wolf CE152TF/S - Page 84

Page 84
Integrated Modules
Integrated Modules
Technical Data
5-8
#826498 - Revision B - November, 2016
Temperature
(°C)
Temperature
(°F)
Resistance
(Ohms)
Tolerance
(±Ohms)
0 32 1000.00 1.20
2 36 1007.81 1.21
4 39 1015.62 1.22
6 43 1023.43 1.23
8 46 1031.23 1.24
10 50 1039.02 1.25
12 54 1046.81 1.26
14 57 1054.6 1.27
16 61 1062.38 1.27
18 64 1070.16 1.28
20 68 1077.93 1.29
22 72 1085.70 1.3
24 75 1093.46 1.31
26 79 1101.22 1.32
28 82 1108.98 1.33
30 86 1116.73 1.34
32 90 1124.47 1.35
34 93 1132.22 1.36
36 97 1139.95 1.37
38 100 1147.69 1.38
40 104 1155.41 1.39
42 108 1163.14 1.4
44 111 1170.85 1.41
46 115 1178.57 1.41
48 118 1186.28 1.42
50 122 1193.98 1.43
52 126 1201.68 1.44
54 129 1209.38 1.45
56 133 1217.07 1.46
58 136 1224.76 1.47
60 140 1232.44 1.48
62 144 1240.12 1.49
64 147 1247.79 1.50
66 151 1255.46 1.51
68 154 1263.12 1.52
70 158 1270.78 1.52
72 162 1278.43 1.53
76 169 1293.72 1.55
78 172 1301.36 1.56
80 176 1308.99 1.57
RTD Temperature and Resistance Chart
