Wolf CG365P/S - Receptacle Installation

Page 15
Remove All Bezels
To remove each bezel:
Use a
3
/
4
" socket to remove the bezel from the unit.
Remove the Light Module
1 Pull the light module forward out of the receptacle.
2 Disconnect the AC-DC rectifier wire connector from the light
module.
Uninstall the Unit
Remove the unit from the installation.
Remove the Receptacle
1 Use a Phillips screwdriver to remove the screws from the
receptacle.
2
Remove the receptacle from the burner valve.
TIP: The spacer(s) typically remain attached to the receptacle.
RECEPTACLE INSTALLATION
Install the Receptacle
1 Install the receptacle onto the burner valve.
2 Use a Phillips screwdriver to install the screws into the
receptacle.
Install the Unit
Install the unit.
Install the Light Module
1 Connect the AC-DC rectifier to the light module.
2 Insert the tabs of the light module into the receptacle.
3 Push the light module into the receptacle.
Install All Bezels
To install each bezel:
1 Insert the bezel into the unit.
2 Use a
3
/
4
" socket to install the bezel on the unit.
Install All Knobs
Push each knob onto each valve shaft.
