Installation Information
15” AND 30” GAS COOKTOP INSTALLATION DIMENSIONS
Area Requirements:
Note: Countertop opening dimensions that are shown must be used. Given dimensions provide required clear-
ances.
E
2
1
/ 2 " min
(6.4)
15"
(38.1)
15"
(38.1)
14"*
(35.6)
4"
(10.2)
5"
(12.7)
G
* Dimensions may vary
by ± 1/8" (.3 cm)
13"
(33.0)
24" or 30"***
18"**
(45.7)
Combined width
of all cooktops
(61.0 or 76.2)
to cooking surface
7"
(17.8)
7"
(17.8)
"*
19
1
/
4
(49.0)
** 18” (45.7cm) minimum clearance upper cabinet to countertop within 7” (17.8cm) minimum side clearance to
combustible surface above countertop.
*** 24” (61cm) minimum clearance between top of cooking surface and bottom of wood or metal cabinet which is
protected by not less than 1/4” (.6cm) flame retardant millboard covered with not less than No. 28 MSG sheet
steel, .015” (.04cm) stainless steel, or .024” (.06cm) aluminum or .02” (.05cm) copper.
*** 30” (76.2) minimum clearance between top of cooking surface and bottom of an unprotected wood or metal
cabinet.
Note: Do not seal cooktop to countertop.
Fig. 3-3. 15” Installation Dimensions
E
3
1
/ 2 "
(8.9)
10"
(25.4)
4"
(10.2)
10"
(25.4)
29"*
(73.7)
19
1
/ 4 "*
(48.9)
2
1
/ 2 "
min
(6.4)
3
1
/ 2 " min
(8.9)
30" oven cutout location
4
3
/ 4 " min
(12.1)
E
G
* Dimensions may vary
by ± 1/8" (.3 cm)
30"
(76.2)
13"
(33.0)
24" or 30"***
(61.0 or 76.2)
18"**
(45.7)
to cooking surface
Fig. 3-4. 30” Installation Dimensions
