Wolf CT36G - Product Features; Overall Dimensions

Installation Notes
A Wolf 36" built-in single oven may be
installed below the 36" gas cooktop. Refer to
specifications for built-in ovens.
Complete installation specifications can be
found on our website, wolfappliance.com.
Unit dimensions may vary by ±
1
/ 8 ".
Specifications
Overall Width 36"
Overall Height 4"
Overall Depth 21"
Burner Rating
(1) 15,000 Btu/hr with 800 Btu/hr delivered
at simmer
(1) 12,000 Btu/hr with 800 Btu/hr delivered
at simmer
(3) 9,200 Btu/hr with 300 Btu/hr delivered
at simmer
Recommended Cabinet Width 39"
Minimum Cabinet Width 36"
Minimum Cabinet Depth 22
3
/4"
Minimum Height Clearance 4"
Countertop Cut-Out Width 35"
Countertop Cut-Out Depth 19
1
/4"
Electrical Requirements 120 V AC, 60 Hz
15 amp circuit
Power Cord 6' cord with grounded plug
Gas Rating 54,600 Btu/hr
Shipping Weight 67 lbs
Installation Specifications
Overall Dimensions
Model CT36G
36" Gas Cooktop
Dimensions in parentheses are in
millimeters unless otherwise specified.
21"
(533)
OVERALL
DEPTH
36" (914)
OVERALL WIDTH
4" (102)
9"*min (229)
CUT-OUT TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
18"
(457)
19
1
/4" (489)
COOKTOP CUT-OUT
DEPTH
2
1
/2"min
(64)
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
13" max
(330)
30" (762)
COUNTERTOP TO
COMBUSTIBLE
MATERIALS
ABOVE COOKTOP
2
1
/2"**
(64)
24"min
(610)
*Minimum clearance from both side edges of cooktop cut-out to combustible materials up to 18" (457) above countertop.
**Minimum clearance from rear edge of cooktop cut-out to combustible materials up to 18" (457) above countertop.
35" (889)
COOKTOP CUT-OUT WIDTH
35" (889)
COOKTOP CUT-OUT WIDTH
39" (991)
RECOMMENDED CABINET WIDTH
36"min (914)
4" (102)
10"
(254)
3
1
/2" (89)
E
G
36-INCH OVEN OPENING
3
3
/4"min (95)
2
1
/2"min
(64)
FRONT OF COUNTERTOP
19
1
/4" (489)
COOKTOP
CUT-OUT DEPTH
Countertop Cut-Out Dimensions
