36" Framed Induction Cooktop
INSTALLATION NOTES
Complete installation specifications can be
found on our website, wolfappliance.com.
Unit dimensions may vary by ±
1
/8".
SPECIFICATIONS
Overall Width 36"
Overall Height 2
1
/2"
Overall Depth 21"
Induction Elements Five
Countertop Cut-Out Width* 34
3
/8"
Countertop Cut-Out Depth 19
1
/4"
Maximum Element Power (2) 1200 W
(2) 1800 W with 3000 W boost
(1) 3000 W with 4000 W boost
Element Diameters 5
1
/2", 6
3
/4",
(2) 8
3
/4" and 11"
Electrical Requirements 240/208 V AC
50/60 Hz, 50 amp circuit
Conduit 4' flexible 3-wire
Electrical Rating 10.2 kW at 240 V AC
8.9 kW at 208 V AC
Shipping Weight 70 lbs
*If the cooktop is to be used with any combina-
tion of additional cooktop units or modules with a
filler strip, the cut-out width increases to 35".
OVERALL DIMENSIONS
36" (914)
2
1
/2" (
64)
1
1
/4" (
32)
7
/8" (22)
ALL SIDES
TERMINAL BOX
21" (533)
18" (457) min
36" (914)
FLOOR TO
COUNTERTOP
30" (762) min
C
OUNTERTOP
TO COMBUSTIBLE
M
ATERIALS
4
1
/2"
(
114
)
10" (254)
3
1
/2" (89)
E
SEE COUNTERTOP
CUT-OUT BELOW
34
3
/8" (873)
CUT-OUT WIDTH
COUNTERTOP CUT-OUT
FRONT
19
1
/4" (489)
CUT-OUT
DEPTH
2
1
/2" (64) min
2" (
51)
TO
C
OMBUSTIBLE
*
2" (
51)
TO
C
OMBUSTIBLE
*
SIDE
CABINET
13" (330)
max
2" (51) min*
FRONT VIEWSIDE VIEW
*Minimum clearance from cooktop cut-out to combustible materials up to 18" (457) above countertop.
NOTE: Electrical location applies only to installation with built-in oven.
INSTALLATION SPECIFICATIONS
Dimensions in parentheses are in
millimeters unless otherwise specified.
