119
FRONT VIEWSIDE VIEW
19" (483)
PLATFORM DEPTH
FRONT VIEWSIDE VIEW
*6" (152) back from countertop cut-out when internal blower is rear mounted.
NOTE: Internal blower 6"
(152) round, side, rear or bottom discharge. In-line and remote blower 10" (254) round, rear discharge.
Centerline indicates center of downdraft cut-out.
21
1
/4"
(540)
8
1
/4"
(210)*
TOP VIEW
W
DOWNDRAFT
CUT-OUT WIDTH
8
1
/4" (210)*
21
1
/4"
(540)
23
3
/8"
(594)
RANGETOP OPENING
2
11
/16" (68)
E
E
Downdraft
INSTALLATION WITH SEALED BURNER RANGETOP
CUT-OUT WIDTH
DOWNDRAFT W
DD30 27
1
/2" (699)
DD36 33
1
/2" (851)
WOLF COOKTOP VENTILATION
RANGES / RANGETOPSOVENS / WARMING DRAWERS OUTDOOR GRILLS VENTILATIONCOOKTOPS / COFFEE SYSTEMS
