FLUSH INSET WIDTH**
FRONT VIEWSIDE VIEW
23" (584)
FLUSH
INSET
DEPTH
7
/8" (22)
18
1
/8" (460)
FLUSH INSET
HEIGHT**
5
/16"(8)
1
/8" (3)
A
TOP VIEW
E
SLIDE
SUPPORT
SLIDE
SUPPORT
FINISHED
CLEATS*
*Will be visible and should be finished to match cabinetry.
**Dimension provides minimum reveals.
Coffee System
FLUSH INSET INSTALLATION
FLUSH INSET WIDTH
COFFEE SYSTEM W A
24" Model 23
3
/4" (603)
13
/16" (21)
30" Trim 30
1
/8" (765) 4" (102)
WOLF COFFEE SYSTEMS
