Wolf SRT486G - Downdraft Dimensions

116 | Wolf Customer Care 800.222.7820
WOLF COOKTOP VENTILATION
RANGES / RANGETOPSVENTILATION COOKTOPS / COFFEE SYSTEMS OVENS / WARMING DRAWERSOUTDOOR GRILLS
2"
(51)
14"
(356)
28
3
/4"
(730)
W
DOWNDRAFT WIDTH
A
CHIMNEY WIDTH
6
3
/4"
(172)
10"
(254)
13"
(330)
13"
(330)
15"
(381)
2
1
/2"
(64)
2
3
/8"
(60)
NOTE: Shown with front mounted internal blower with 6" (152) round discharge,
dashed line represents rear mount.
Downdraft
DIMENSIONS
WIDTH
MODEL W A
DD30 30" (762) 26
1
/2" (673)
DD36 36" (914) 32
1
/2" (826)
DD45 45" (1143) 38
1
/2" (978)
