M Series Single Oven
STANDARD INSTALLATION
E
5"
(127)
E
E
4"
(102)
FRONT VIEWSIDE VIEW
NOTE: Location of electrical supply within opening may require additional cabinet depth.
23
1
/4" (591)
OPENING
DEPTH
TOP VIEW
W
OPENING WIDTH
27
1
/2"
(699)
OPENING
HEIGHT
OPENING WIDTH
SINGLE OVEN W
27" Model 25
1
/2" (648)
30" Model 28
1
/2" (724)
36" Model 34
1
/2" (876)
WOLF BUILT-IN OVENS
