17
INSTALL TOILET SEAT
Install the Toilet Seat using the
instructions included within the Toilet
Seat packaging.
LESS WATER
PER FLUSH
MORE WATER
PER FLUSH
FLAPPER ADJUSTMENT
This Toilet includes an Adjustable Flapper that allows the installer to adjust the volume of water used per flush. This Adjustable Flapper comes
pre-adjusted to use 1.28 gallons / 4.8 liters per flush. If your installation requires a different volume of water per flush, access the underside of
the Adjustable Flapper and rotate the adjustment wheel towards the minus symbol (
-
) for MORE water used per flush, or towards the plus
symbol (
+
) for LESS water used per flush.
1
A
Turn OFF water supplies (A). Lift handle of
Filter (B). Rotate Filter counter-clockwise
while holding the Rotational Dial stationary
(C).
2
Once Filter is released, pull upward to
remove from the Fill Valve.
3
Clean Filter by rinsing under running water.
4
MAINTENANCE: FILL VALVE FILTER CLEANING
Insert the Filter into the Fill Valve while
aligning the Tabs (A). Rotate Filter
clockwise while holding the Rotational Dial
stationary until Filter locks into position
(B). Turn ON water supplies (C).
TROUBLESHOOTING
Issue: Water level in Tank is too high or too low
Cause: Fill Valve is not adjusted to the desired position.
Solution: Adjust water level by following the “Water Level Adjustment” section.
Issue: Fill Valve does not turn ON
Cause: Water Supply is OFF.
Solution: Turn ON Water Supply. If Fill Valve is still not functional, turn OFF Water
Supply and clean Filter Screen by following the “Filter Cleaning” section
in this manual.
Issue: Fill Valve does not turn OFF
Cause: Refill Tube wasn’t installed properly.
Solution: Re-install the Refill Tube and ensure that Refill Tube Outlet is above the
water level when Tank is full.
PRODUCT WARRANTY
Wolverine Brass will, at its election, repair, replace, or make appropriate adjustment where Wolverine Brass' inspection
discloses any such defects occurring in normal usage. Damage caused by accident, misuse, or abuse is not covered by
this warranty. Improper care and cleaning will void the warranty. Use of Chlorine or chemically related components will
void the warranty. Proof of purchase (original sales receipt) must be provided to Wolverine Brass with all warranty claims.
Wolverine Brass is not responsible for removal, installation, labor charges, or other incidental or consequential costs. In no
event shall the liability of Wolverine Brass exceed the purchase price of the toilet.
*Mechanical Component Limited Warranty varies based on component affected. Please call 1-800-944-9292 for additional information.
CALIFORNIA PROPOSITION 65
CALIFORNIA PROPOSITION 65:
WARNING: This product can expose you to chemicals including lead, which is known to
the State of California to cause cancer and birth defects or other reproductive harm. For
more information go to www.P65Warnings.ca.gov.
Wash hands after installation, repair, or removal of this product.
COMPLIANCE
CONNECTIONS
ASME A112.19.2/CSA B45.1
cUPC certified
WaterSense certified
3/8” Compression (Inlet Hose Connection - Included)
12” Rough-In to wall
39707 ROUGH-IN DIAGRAM
