Wood-mizer LT70 User Manual

REPLACEMENT PARTS
Hydraulic Control Box, 12-Section Remote Super
REPLACEMENT PARTS doc070822 3-14
3
11 BOLT, 1/4-20X1/2 HH F05005-15 2
12 WASHER, Z 6.1 SPLIT LOCK ZINC F81053-3 2
13 FITTING, #4 SAE - #6 SAE 45¶ ELBOW 015488 7
14 FITTING, #6 SAE 45¶ ELBOW 015489 1
15 FITTING, 6SAE MALE-1/4NPT FEMALE 014686 3
16 FITTING, 1/4NPT-3/8 BARB 014685 1
17 FITTING, 3/8 O-RING-3/8JIC 014687 10
18 FITTING, 1/4JIC-3/8 O-RING P26284 8
19 HYDRAULIC PUMP, AC 18.5L/ 5.5 KW (22.049 517840 1
20 FITTING, 1/4 BRANCH TEE 015486 1
21 FITTING, 3/8JIC-1/4NPT 90L 015491 1
22 PLUG, 1/4-18 NPT BLANK 096221 1
23 FITTING, 3/8NPT-3/8 BARB ELBOW P12708 1
24 BOLT, #10-24X1/2 SELF-TAPPING F05015-7 16
25 SEAL, RUBBER VALVE HANDLE 015079 2
26 BRACKET, HYDRAULIC CONTROL BOX BASE - COMPLETE 539352-1 1
27 WASHER, 8.4 FLAT ZINC F81054-1 48
28 NUT, M8-8-B HEX NYLON ZINC LOCK F81032-2 19
29 BOLT, M8X25-8.8-B HEX HEAD FULL THREAD ZINC F81002-5 14
30 PLATE, REMOTE HYDRAULIC CONTROL BOX REAR 500516-1 1
31 BOLT, M8X20 8.8 HEX HEAD FULL THREAD ZINC F81002-4 4
32 GUARD, LT70 AC REMOTE CONTROL BOX (PC) 090219 1
33 BRACKET, CONTROL BOX GUARD 500766-1 1
34 BRACKET, CONTROL BOX GUARD - LEFT 500767-1 1
35 WASHER, 10.5 FLAT ZINC F81055-1 20
36 NUT, M10-8-B HEX NYLON ZINC LOCK F81033-1 8
37 BOLT,M10X35-8.8 HEX HEAD FULL THREAD ZINC F81003-17 4
38 BOLT, M10X25 8.8 HEX HEAD FULL THREAD ZINC F81003-11 8
39 BOLT, M8X16-8.8-B HEX HEAD FULL THREAD ZINC F81002-20 12
40 WASHER, 6.4 FLAT ZINC F81053-1 6
41 GUARD, CABLE 501102-1 1
42 CAP, 44.5 MM NO. 466923 HOLE 500768 1
43 BUSH, MOSS 44.5MM 465901 SNAP-FIT R80670-3 1
44 BOLT, M8X30 8.8 HEX HEAD FULL THREAD ZINC F81002-7 4
45 WASHER, 13 FLAT ZINC F81056-1 4
46 BOLT, M12X35 8.8 HEX HEAD FULL THREAD ZINC F81004-24 2
47 NUT, M12-8 HEX NYLON ZINC LOCK F81034-2 1
48 MICROSWITCH, HYDRAULIC VALVE 014765 2
49 CONTACT ASSEMBLY, LT40/70 AC NEGATIVE 086624 1
50 CONTACT ASSEMBLY, LT40/70 AC POSITIVE 086625 1
51 GROMMET, RUBBER 089532 1
52 SLEEVE, LT40/70 0.6 THICK 3.5 LONG PROTECTIVE 510287 1
- BASE, SR CONTROL BOX TRANSPORT - COMPLETE 550066 1
53 BASE WELDMENT, SR CONTROL BOX TRANSPORT 550063-1 2
54 BAR, CONTROL BOX TRANSPORT BASE 550065-1 1
REF DESCRIPTION ( indicates parts available in assemblies only) PART # QTY
