Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 102/179 © Woodward
Parameter 165
Gen.overcurrent
limit 2 000%
Independent time-overcurrent, threshold value, limit 2 0 to 300 %
If the monitored generator current exceeds the configured percentage of the rated
generator current for at least the delay time configured in Parameter 166, an F3
class alarm
is issued.
Issuing of F3 class alarm
Parameter 166
Gen.overcurrent
delay 2 00.00s
Independent time-overcurrent, delay, limit 2 0.02 to 9.98 s
For the control unit to recognize that a time-overcurrent fault has occurred, the
threshold value configured in Parameter 165) must be exceeded without interrup-
t
ion for this period of time.
Parameter 167
Gen.overcurrent
Cool down ON
Open GCB with engine cool down due to overcurrent ON/OFF
ON ................ If the GCB is opened due to an overcurrent fault condition, an engine
cool-down is performed prior to engine stop.
OFF .............. The engine is stopped without a cool-down.
