Woodward GCP-30 Series User Manual

Manual 37365A GCP-30 Series Packages - Genset Control
Page 160/179 © Woodward
MUX
No.
Contents (words)
Unit Note
22/2 68
Alarm messages IKD2 (SC10) Bit 15 = 1 Failure DI8 of the IKD1.2
Bit 14 = 1 Failure DI7 of the IKD1.2
Note – On double /fourfold bits the follow-
ing is valid: If the indicated bit combination
is fulfilled (
high byte and low byte) ,the
message is active (otherwise inactive).
Bit 13 = 1 Failure DI6 of the IKD1.2
Bit 12 = 1 Failure DI5 of the IKD1.2
Bit 11 = 1 Failure DI4 of the IKD1.2
Bit 10 = 1 Failure DI3 of the IKD1.2
Bit 9 = 1 Failure DI2 of the IKD1.2
Bit 8 = 1 Failure DI1 of the IKD1.2
Bit 7 = 1 --Internal--
Bit 6 = 1 --Internal--
Bit 5 = 1 --Internal--
Bit 4 = 1 --Internal--
Bit 3 = 1 --Internal--
Bit 2 = 1 --Internal--
Bit 1 = 1 --Internal--
Bit 0 = 1 --Internal--
22/3 69
LCD-display / Pickup Currently active display message
Bit 15 = x
A number is transmitted, please consult
the table for the meaning of the num-
ber 69 of the telegram "Monitoring of the
active display".
Bit 14 = x
Bit 13 = x
Bit 12 = x
Bit 11 = x
Bit 10 = x
Bit 9 = x
Bit 8 = x
Pickup
Bit 7 = 1
Firing speed reached
f > parameter
Bit 6 = 1
Bit 5 = 1
Bit 4 = 1
Bit 3 = 1
Speed existing
without pickup (pickup = OFF): f > 15
Hz
with pickup (pickup = ON): f > 5 Hz
Bit 2 = 1
Bit 1 = 1
Bit 0 = 1
UGNEXPO Exponent Generator voltage USSEXPO Exponent Busbar voltage
IGNEXPO Exponent Generator current UNTEXPO Exponent Mains voltage
PGNEXPO Exponent Generator power PNTEXPO Exponent Mains power
PGNWD Step conversion factor  kW
