Worcester Benchmark Danesmoor Utility 12/14 User Manual

7
Fig. 2. Conventional Flue Appliance (CF/LLD).
Burner locking
screw
Burner seal
gasket
Side panel
locking screw (A)
Burner
Optional pump
location
Manual reset
overheat
thermostat
Strain relief
bush
Burner plug-in
connector
High limit thermostat
Fire valve clip
Side panel
Top panel
Front panel
Thermostat
knob
Manual reset over-
heat thermostat
phial
Automatic reset high
limit thermostat phial
Control thermostat
phial
Split pin
Control Box Assembly
