Ethernet port
Main supply port
Supply optional port
Multifunction connection port,
PIN
Contact
1
GPIO 1
2
GPIO 2
3
GND
4
GPIO 3
5
GPIO 4
6
GND
7
GPIO 5
8
GPIO 6
9
GPIO 7
10
GPIO 8
11
GND
12
GPIO 9
13
GPIO 10
14
A 1
15
A 2
