--5--
Input Connection
Microphones
Three microphone inputs are provided. They used with
unbalanced low impedance (30~600 ohms) microphoe. The
microphone with the unbalanced connection cable of 10-20m
may be used depending on the microphone and its
characteristic.
MIC-1, MIC-2
There TWO microphone inputs are unbalanced type and are
provided with a double pole phone jack.
Unbalanced Lo Z Microphone
May also be connected to the single conductor shielded
cable of unbalanced Lo Z microphone.
AUX/PHONE
A radio tuner, tape player, chime , mixer preamplifer, compact
disk player or other high level input sources may be
connected to the AUX inputs.
MIC
AUX
Single pole phone plug
Unbalanced microphone
PHONO
L
B
SELECTOR SWITCH
PHONO AUX/CD
Should be selected either AUX or PHONO by using. The
AUX/PHONO Selector switch on the rear panel. AUX &
PHONO connot be used at the same time.
Output Connection
--12--
COM
PRIORITY
100V
4W
8W
16W
CONTROL MUTE (PRIORIDAD)
MIC1
MIC2
PHONO / AUX
MASTER VOLUME
-10 +10MIN MAX -10 +10MIN MAX
1kHz
0
150kHz
0
6kHz
0
-10 +10
FREQUENCY EQUALIZER
10
11
9
12
8
3
1
7
14
6
1
5
5
6
4
1
17
3
2 18
1 19
0
2
0
8 7 6 5 4 3 2 1
AC FUSE
GND
AUX/CD
PHONO
MIC1
MIC2
AUX PHONO
L
R
CAUTION:
TO REDUCE THE RISK OF FIRE
REPLACE ONLY WITH SAME TYPE
AC FUSE.
PRIORITY COM 100V4W 8W 16W
9 18 17 16
131110
15
1412
OUTPUT
Rheinland
Production inspected
Rheinland
Product Safety
geprufte
Sicherheit
POWER
PA 50 CA TWO SERIES
PUBLIC ADRESS AMPLIFIER
Cuando se cortocircuitan los terminales, las entradas MIC2,
AUX, y PHONO se apagan y MIC1 tiene prioridad.
1. Evite usar o almacenar la unidad en un lugar polvoriento.
2. No lo utilice bajo la luz solar directa o cerca de estufas o
fuentes de calor similares.
