OPERATION AND SERVICE INFORMATION
3-20
Read all of manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings
If only front or rear of vehicle is to be raised, place the chocks in front
and behind each wheel not being raised in order to stabilize the vehicle.
Lower the vehicle by reversing the lifting sequence.
WHEELS AND TIRES
Standard tires for this vehicle are uni-directional
and should never be moved from one side of vehi-
cle to the other.
This vehicle comes standard with uni-directional tires. Left side tires
should always remain on the left side of the vehicle. Right side tires
should always remain on the right side of the vehicle. Uni-directional
tires have an arrow on the sidewall indicating direction of rotation when
moving forward. Tire condition should be inspected per the Periodic
Service Schedule (Ref Fig. 22 on page 3-28). Inflation pressures
should be checked when the tires are cool. Be sure to install valve dust
cap after checking or inflating.
Tire Repair
Tool List Qty. Required
Lug wrench, 3/4" ...................................................................1
Impact socket, 3/4", 1/2" drive...............................................1
Impact wrench, 1/2" drive......................................................1
Torque wrench, 1/2" drive......................................................1
A tire explosion can cause
severe injury or death. Never
exceed inflation pressure rat-
ing on tire sidewall.
To reduce the possibility of tire explosion, pres-
! !
Fig. 16 Lifting the Vehicle
View from Underside of Vehicle
