WORKHORSE CUSTOM CHASSIS
Service Manual
W SeriesWCC
SECTION
6.2
PAGE
5
Engine Mechanical
W Series Chassis
TOC
© 2006 WorkhorseCustom Chassis — All Rights Reserved
Drive Belt Tensioner Bolt 50 N·m 37 lb ft
Engine Block Coolant Drain Hole M28 Plug - Left Front 60 N·m 44 lb ft
Engine Block Coolant Drain Hole Plug - Side 30 N·m 22 lb ft
Engine Block Coolant Heater 50 N·m 37 lb ft
Engine Block Oil Gallery Plug - Front 20 N·m 15 lb ft
Engine Block Oil Gallery Plug - Rear 30 N·m 22 lb ft
Engine Block Oil Gallery Plug - Side 30 N·m 22 lb ft
Engine Block Oil Gallery Plug - Top 20 N·m 15 lb ft
Engine Coolant Crossover Bolt 50 N·m 37 lb ft
Engine Coolant Temperature (ECT) Senso 50 N·m 37 lb ft
Engine Coolant Temperature (ECT) Sensor Bracket Bolt 50 N·m 37 lb ft
Engine Harness Bolt 5 N·m 44 lb in
Engine Harness Ground Bolt 16 N·m 12 lb ft
Engine Harness Stud 10 N·m 89 lb in
Engine Lift Bracket Bolt 40 N·m 30 lb ft
Engine Mount-to-Engine Bolt 50 N·m 37 lb ft
Engine Shield Bolt 20 N·m 15 lb ft
Engine Sight Shield Bracket Nut 5 N·m 44 lb in
Engine Wiring Harness Bolt 16 N·m 12 lb ft
Evaporative Emission (EVAP) Canister Purge Solenoid Valve Bolt 8 N·m 71 lb in
Exhaust Gas Recirculation (EGR) Valve Opening Cover Nut 22 N·m 16 lb ft
Exhaust Gas Recirculation (EGR) Valve Opening Cover Stud 7 N·m 62 lb in
Exhaust Manifold Center Bolt 5 N·m 26 lb ft
Exhaust Manifold Nut 16 N·m 12 lb ft
Exhaust Manifold Stud 20 N·m 15 lb ft
Exhaust Manifold Heat Shield Bolt 25 N·m 18 lb ft
Exhaust Manifold Heat Shield Nut 25 N·m 18 lb ft
Flywheel Bolt - First Pass 40 N·m 30 lb ft
Flywheel Bolt - Second Pass 80 N·m 59 lb ft
