WORKHORSE CUSTOM CHASSIS
Service Manual
W SeriesWCC
SECTION
6.2
PAGE
6
Engine Mechanical
W Series Chassis
TOC
© 2006 WorkhorseCustom Chassis — All Rights Reserved
Flywheel Bolt - Final Pass 100 N·m 74 lb ft
Front Cover Bolt - First Pass 6 N·m 53 lb in
Front Cover Bolt - Final Pass 12 N·m 106 lb in
Fuel Rail Bolt/Stud 12 N·m 106 lb in
Heater Hose Bracket Bolt 50 N·m 37 lb ft
Hood Hinge Bolt 25 N·m 18 lb ft
Ignition Coil Bolt 12 N·m 106 lb in
Ignition Coil Wiring Harness Bolt 12 N·m 106 lb in
Intake Manifold Bolts - First Pass In Sequence 5 N·m 44 lb in
Intake Manifold Bolts - Second Pass In Sequence 8 N·m 71 lb in
Intake Manifold Bolts - Third Pass In Sequence 12 N·m 106 lb in
Intake Manifold Bolt - Final Pass In Sequence 15 N·m 11 lb ft
J 36857 Bolt 40 N·m 30 lb ft
J 42847 Bolt 50 N·m 37 lb ft
Knock Sensor 20 N·m 15 lb ft
Knock Sensor Heat Shield Bolt 12 N·m 106 lb in
Manifold Absolute Pressure (MAP) Sensor Bolt 12 N·m 106 lb in
Oil Cooler Hose Fittings 23 N·m 17 lb ft
Oil Fill Tube Bolt 12 N·m 106 lb in
Oil Level Sensor 20 N·m 15 lb ft
Oil Pan Bolt - First Pass 10 N·m 89 lb in
Oil Pan Bolt - Final Pass 25 N·m 18 lb ft
Oil Pan Drain Plug 28 N·m 21 lb ft
Oil Pan Skid Plate Bolt 20 N·m 15 lb ft
Oil Pressure Sensor 30 N·m 22 lb ft
Oil Pump Bolt 75 N·m 56 lb ft
Oil Pump Cover Bolt 12 N·m 106 lb in
Oil Pump Drive Bolt 25 N·m 18 lb ft
Power Steering Pump Bracket Bolt/Nut 50 N·m 37 lb ft
