WORKHORSE CUSTOM CHASSIS
Service Manual
W SeriesWCC
SECTION
6.2
PAGE
68
Engine Mechanical
W Series Chassis
TOC
© 2006 WorkhorseCustom Chassis — All Rights Reserved
SEPARATING PARTS
Important: Many internal engine components will develop specifi c wear patterns on their friction surfaces.
When disassembling the engine, internal components MUST be separated, marked or organized in a way to ensure
reinstallation to original location and position.
Separate, mark, or organize the following components:
Piston to the specifi c cylinder bore
Piston rings to the piston
Connecting rod to the crankshaft journal
Connecting rod to the bearing cap
Crankshaft and connecting rod bearings
Camshaft and valve lifters
Valve lifters, guides, pushrods, pivot supports and rocker arms
Valve to the valve guide
Valve spring and shim to the cylinder head location
Engine block crankshaft bearing cap location and direction
Oil pump drive and driven gears
