WORKHORSE CUSTOM CHASSIS
Service Manual
W SeriesWCC
SECTION
6.2
PAGE
76
Engine Mechanical
W Series Chassis
TOC
© 2006 WorkhorseCustom Chassis — All Rights Reserved
Crankshaft Bearing Cap M10 Studs - First Pass in Sequence
20 N·m 15 lb ft
Crankshaft Bearing Cap M10 Studs - Final Pass in Sequence
51 degrees
Crankshaft Oil Defl ector Nut
25 N·m 18 lb ft
Crankshaft Position (CKP) Sensor Bolt
25 N·m 18 lb ft
Crossbar Bolt
100 N·m 74 lb ft
Cylinder Head M8 Bolts - in Sequence
30 N·m 22 lb ft
Cylinder Head M11 Bolts - First Pass in Sequence
30 N·m 22 lb ft
Cylinder Head M11 Bolts - Second Pass in Sequence
90 degrees
Cylinder Head M11 Bolts - Final Pass in Sequence
70 degrees
Cylinder Head Coolant Plug
20 N·m 15 lb ft
Differential Carrier Lower Mounting Bolt/Nut
100 N·m 74 lb ft
Drive Belt Idler Pulley Bolt
50 N·m 37 lb ft
Drive Belt Tensioner Bolt
50 N·m 37 lb ft
Engine Block Coolant Drain Hole Plug
60 N·m 44 lb ft
Engine Block Coolant Heater
50 N·m 37 lb ft
Engine Block Oil Gallery Plugs
60 N·m 44 lb ft
Engine Coolant Air Bleed Pipe and Cover Bolts
12 N·m 106 lb in
Engine Coolant Fitting - RPO HP2
35 N·m 26 lb ft
Engine Harness Ground Bolt - Right Rear
16 N·m 12 lb ft
Engine Harness Ground Bolt-to-Block
25 N·m 18 lb ft
Engine Mount Bolt
50 N·m 37 lb ft
Engine Mount Bracket Through Bolt
75 N·m 55 lb ft
Engine Mount-to-Engine Mount Bracket Bolt
65 N·m 50 lb ft
Engine Shield Bolt
20 N·m 15 lb ft
Engine Wiring Harness Bracket Nut
5 N·m 44 lb in
Evaporative Emission (EVAP) Canister Purge Solenoid Valve Bolt
10 N·m 89 lb in
Exhaust Manifold Bolts - First Pass
15 N·m 11 lb ft
Exhaust Manifold Bolts - Final Pass
25 N·m 18 lb ft
Exhaust Manifold Heat Shield Bolts
9 N·m 80 lb in
Flex Plate/Rotor Bolts - RPO HP2
100 N·m 74 lb ft
