PARTIS LIST
Please refer to the schematic drawing, p.10
DESCRIPTIONNO QTYDESCRIPTION QTYNO DESCRIPTION QTYNO
1
Cable
1
2
Cable armor
1
3
Cable Sleeve
1
4
ST4 X 14
2
5
&DSDFLWDQFHȝ)
1
6
Carbon brush
2
7
Carbon brush holder
1
8
Electromotor shuck
1
9
Switch
1
10
Handgrip sheath
1
11
Nut M6
5
12
Electromotor shuck
1
13
St4 x 16
8
14
Axis
1
15
Plotting
1
16
Nut m5
8
17
Stator
1
18
Bearing 608z
1
19
Rotor
1
20
bearing 608z
1
21
Small zonal wheel
1
22
Bearing 607z
1
23
Transmission zonal
1
24
Retainer ring 10
3
25
Big zonal wheel
1
26
Dowel 3 x 5
1
27
Dutput spindle
1
28
Press board
2
29
Grnding wheel[ ø100]
1
30
Gasket 8
4
31
Nut M8
3
32
Bolt M5 X 16
2
33
Protcet cover
1
34
Clamp knob
2
35
Gasket 5
2
36
Bolt M5 X 20
2
37
Passport 1
Adjust bolt (1)
38
2
Nut M6
39
1
Nut M6 X 12
40
2
Bracket
41
1
Bolt M5 X 35
42
1
Left slip piece
43
1
Right slip piece
44
1
Bolt M5 X 10
45
1
Block piece
46
1
Nut M5
47
1
Spring (1)
48
1
Saw press board
49
2
Bolt M8 X 50
50
1
Bearing 6000z
51
1
Spring (2)
52
2
Gasket 6
53
5
Bolt M6 X 16
54
2
Right press board
55
1
Left press borad
56
1
Bolt M6 X 12
57
1
Bracket
58
1
Adjust bolt (2)
59
1
Spring (3)
60
1
Nut M8
61
1
Locknut
62
1
Orientatior board
63
1
Base
64
1
Spring
65
1
Steel ball SØ5
66
1
Bolt M4 X 10
67
1
Splint
68
1
Turning dais
69
1
Spring
70
2
Press board
71
1
Bolt M8X80
72
1
Wrench (4x22x60)
73
1
Wrench (4x22x65)
74
1
