Worx WX317.2 User Manual

Impact drill EN
11
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
SECURE WORKPIECE
A workpiece clamped with clamping devices is held
more secure than by hand.
INTENDED USE
The machine is intended for impact drilling in brick,
concrete and stone as well as for drilling in wood,
metal and plastic.
ASSEMBLY AND OPERATION
ACTION FIGURE
Clamping and loosening the
Auxiliary Handle
WARNING! Always check
and rotate the handle
tightly before using to avoid any
accident.
See Fig. A1, A2
Installing the Depth Gauge See Fig. B
Inserting Bits into Chuck See Fig. C1, C2
Plugging in the power See Fig. D
On/Off Switch and Lock-on
Button
See Fig. E
Variable Speed Control See Fig. F
Forward and Reverse Rotation
Control
NOTE Never move the
forward/reverse switch
whilst the drill in operation or
the on/off switch is locked as
this will damage the drill.
See Fig. G
Hammer or Drilling Control See Fig. H
WORKING HINTS FOR YOUR
DRILL
1. Drilling masonry and concrete
Select the drill/impact action selector switch to the
“hammer symbol” position. Tungsten carbide drill bits
should always be used for drilling masonry, concrete
etc with a high speed.
2. Drilling steel
Select the drill/impact action selector switch to the “drill
symbol” position. HSS drill bits should always be used for
drilling steel with a lower speed.
3. Pilot holes
When drilling a large hole in tough material (i.e. steel),
we recommend drilling a small pilot hole first before
using a large drill bit.
4. Drilling tiles
Select the drill/impact action selector switch to the “drill
symbol” position to drill the tile. When tile has been
penetrated, switch over to “hammer symbol” position.
5. Cool the motor
If your power tool becomes too hot, set the speed to
maximum and run no load for 2-3 minutes to cool the
motor.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional lubrication or
maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through the
ventilation slots. This is normal and will not damage
your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
If the replacement of the supply cord is necessary, this
has to be done by the manufacturer or his agent in
order to avoid a safety hazard.
TROUBLESHOOTING
1. If your power tool does not start, check the plug
on the power supply first.
2. If the drill doesn’t work properly, check the drill
bit for sharpness, replace drill bit if worn. Check
that the drill is set to forward rotation for normal
use.

Worx WX317.2 Specifications

General

Drilling	Yes
Chuck type	-
Product color	Black, Orange
Input power	600 W
Power source	AC
AC input voltage	230-240 V
AC input frequency	50 Hz
Impact rate	48000 bpm
Rated speed (max)	3000 RPM
Drilling diameter in wood (max)	25 mm
Drilling diameter in concrete (max)	13 mm

Weight and Dimensions

Weight	2100 g
