Worx WX317.2 User Manual

Impact drill EN
9
1. KEYLESS CHUCK
2. DEPTH GAUGE
3. DRILL HAMMER DRILL FUNCTION SELECTOR
4. SWITCH LOCK ON BUTTON
5. ONOFF SWITCH
6. VARIABLE SPEED CONTROL
7. FORWARD AND REVERSE ROTATION CONTROL LEVER
8. AUXILIARY HANDLE
Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WX317 WX317.2 WX318 (300-329-designation of machinery, representative of Impact Drill)
WX317 WX317.2 WX318
Voltage
230-240V~50Hz
Power input
600W 810W
No load speed
0-3000/min
Impact rate
0-48000/min
Chuck capacity
13mm
Drilling capacity
Masonry
13mm 16 mm
Wood
25mm 32 mm
Steel
13mm 13 mm
Protection class
/II
Machine weight
1.6kg 2.42kg
NOISE INFORMATION
WX317 WX317.2 WX318
A weighted sound pressure L
pA
: 99dB(A) L
pA
: 93,5dB(A)
A weighted sound power L
wA
: 110dB(A) L
wA
: 104,5dB(A)
K
pA
& K
wA
5.0 dB (A)
Wear ear protection

Worx WX317.2 Specifications

General

Drilling	Yes
Chuck type	-
Product color	Black, Orange
Input power	600 W
Power source	AC
AC input voltage	230-240 V
AC input frequency	50 Hz
Impact rate	48000 bpm
Rated speed (max)	3000 RPM
Drilling diameter in wood (max)	25 mm
Drilling diameter in concrete (max)	13 mm

Weight and Dimensions

Weight	2100 g
