Worx WX372 User Manual

Lithium-Ion cordless hammer drill EN
7
6
1. CHUCK
2. TORQUE ADJUSTMENT RING
3. TWO-SPEED GEAR CONTROL
4. FORWARD/REVERSE ROTATION CONTROL
5. SOFT GRIP HANDLE
6. BATTERY PACK *
7. BATTERY PACK RELEASE BUTTON
8. SIGHT LIGHT
9. ON/OFF SWITCH
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Type WX372 WX372.1 WX372.2 WX372.3 WX372.4 WX372.5 WX372.7 WX372.8
WX372.9 WX372.10 (3-designation of machinery, representative of hammer drill)
WX372 WX372.1 WX372.2
WX372.3 WX372.4 WX372.5
WX372.8 WX372.10
WX372.7 WX372.9
Rated voltage 20V Max**
No load speed 0-550 / 0-1800/min
Impact rate 0-8800 / 0-28800/min
Number of clutch position 22+1+1
Max torque 50N.m
Chuck capacity 13mm
Max. drilling
capacity
Steel 13mm
Wood 40mm
Brickwork 16mm
Concrete 13mm
Machine weight 1.65kg 1.98kg 1.29kg
**Voltage measured without workload. Initial battery voltage reaches Maximum of 20volts.
Nominal voltage is 18volts.

Worx WX372 Specifications

General

Power source	Battery
Charging time	60 min
Battery voltage	20 V
Battery capacity	2 Ah
Battery included	Yes
Number of batteries included	2 pc(s)
Chuck type	Keyless
Motor type	Brushed
Screwdriving	-
Product design	Pistol grip drill
Torque (max)	50 N⋅m
Number of gears	22
Idle speed (max)	1800 RPM
Idle speed (min)	550 RPM
Chuck capacity (max)	13 mm
Impact rate (high speed)	28800 bpm
Drilling diameter in wood (max)	40 mm
Drilling diameter in concrete (max)	12 mm
Product color	Black, Orange, Silver

Weight and Dimensions

Depth	66 mm
Width	216 mm
Height	189 mm
Weight	1650 g
