Angle Grinder EN
9
VIBRATION INFORMATION
Vibration total values (triax vector sum)
determined according to EN 60745:
Typical weighted
vibration
Vibration emission
value a
h,AG
= 5.513 m/s
2
Uncertainty K=1.5m/s
2
The declared vibration total value may be used for
comparing one tool with another, and may also be
used in a preliminary assessment of exposure.
WARNING: The vibration emission value
during actual use of the power tool can differ
from the declared value depending on the ways in
which the tool is used dependant on the following
examples and other variations on how the tool is
used:
How the tool is used and the materials being cut.
The tool being in good condition and well
maintained
To use the correct accessory for the tool and
ensuring it is sharp and in good condition.
The tightness of the grip on the handles and if any
anti vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.
This tool may cause hand-arm vibration
syndrome if its use is not adequately managed
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing
the job. This may significantly reduce the exposure
level over the total working period.
Helping to minimize your vibration exposure risk.
Maintain this tool in accordance with these
instructions and keep well lubricated (where
appropriate).
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high
vibration tool use across a number of days.
ACCESSORIES
Spanner 1
Auxiliary handle 1
Metal grinding disc 1
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The machine is intended for cutting, roughing and
brushing metal and stone materials without using
water. For cutting metal, a special protection guard
for cutting (accessory) must be used.
ASSEMBLY AND OPERATION
ACTION FIGURE
ASSEMBLY
Assembling Auxiliary Handle See Fig. A
Assembling Grinding/Cutting Disc See Fig. B
Adjusting Outer Flange Clamping See Fig. C
OPERATION
Using On/Off Switch See Fig. D
Hand Grip Areas
Rough Grinding
WARNING! Never use a
cutting disc for roughing.
See Fig. E
Cutting
WHEEL GUARD FOR CUTTING
(NOT SUPPLIED)
WARNING! For cutting metal,
always work with the wheel
guard for cutting.
See Fig. F
WORKING HINTS FOR YOUR
ANGLE GRINDER
1. Always start at no load to achieve maximum
speed then start working.
2. Do not force the disc to work faster, reducing the
Disc’s moving speed means longer working time.
3. Always work with a 15-30 angle between disc and
workpiece. Larger angles will cut ridges into the
workpiece and affect the surface finish. Move the
angle grinder across and back and forth over the
workpiece.
4. When using a cutting disc never change the
cutting angle otherwise you will stall the disc
and angle grinder motor or break the disc. When
cutting, only cut in the opposite direction to the
disc rotation. If you cut in the same direction as
the disc rotation the disc may push itself out of
the cut slot.
5. When cutting very hard material best results can
be achieved with a diamond disc.
